Mini Cement Grinding Plant Ball Mill

  • Mini Cement Grinding Plant Ball Mill
  • Mini Cement Grinding Plant Ball Mill
  • Mini Cement Grinding Plant Ball Mill
  • Mini Cement Grinding Plant Ball Mill

Mini Cement Grinding Plant Ball Mill

    Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
    Terms of Trade: FOB,CFR,CIF
    Min. Order: 1 Set/Sets
    Delivery Time: 30 Days
    Packaging: Container Loading
    Productivity: 2-75 t/h
    Brand: Mingyuan
    Transportation: Ocean
    Place of Origin: Henan, China
    Supply Ability: 5 sets per month
    Certificate: CE, ISO
    HS Code: 8430310000
    Port: Qingdao Port,Tianjin Port,Shanghai Port

Basic Info

Model No.: 1200*4500

Product Description

Mini Cement Grinding Plant Ball Mill For Sale

The ball mill machine changes the intrinsic grinding machine structure. Its body and ground plank are an integral whole. So when fixing, it can be lowered onto a basal plane once only. Using biserial roller axletree with centripetal spherical support of the host axletree can reduce energy consumption by 30%. The intrinsic grille pattern forced discharging is substituted by the ovefall pattern controlling one. This can improve the milled granularity and the capacity can be increased by 15-20%.

Working principle of Mini Cement Grinding Plant Ball Mill For Sale

The Ball Mill is horizontal cylindrical rotation device, driven by brim gearwheel. There are two chambers and grid. Material goes into the first chamber through the feeding inlet. Inside the first chamber, there are stage liners and ripple liners as well as steel balls. The shell rotates so as to generate electricity, and this force brings ball to a certain height and then balls drop down by gravity, the impact is the grinding force to the material. After the primary grinding, materials go into the second chamber through segregate screen. In the second chamber, there are flat liners and steel ball, after the secondary grinding, material is discharged from the discharging.

Mini Ball Mill


Specification of Mini Cement Grinding Plant Ball Mill For Sale

Model

speed
(r/min)

Ball load
(t)

Feeding size
(mm)

Discharging size
(mm)

Capacity
(t/h)

Motor power
(kw)

Total weight
(t)

Ф900×1800

36-38

1.5

≤20

0.075-0.89

0.65-2

18.5

5.5

Ф900×3000

36

2.7

≤20

0.075-0.89

1.1-3.5

22

6.7

Ф1200×2400

36

3

≤25

0.075-0.6

1.5-4.8

30

12

Ф1200×3000

36

3.5

≤25

0.074-0.4

1.6-5

37

12.8

Ф1200×4500

32.4

5

≤25

0.074-0.4

1.6-5.8

55

13.8

Ф1500×3000

29.7

7.5

≤25

0.074-0.4

2-5

75

16.8

Ф1500×4500

27

11

≤25

0.074-0.4

3-6

110

21

Ф1500×5700

28

12

≤25

0.074-0.4

3.5-6

130

25.8

Ф1830×3000

25.4

11

≤25

0.074-0.4

4-10

130

29

Ф1830×4500

25.4

15

≤25

0.074-0.4

4.5-12

155

35.5

Ф1830×6400

24.1

21

≤25

0.074-0.4

6.5-15

210

43

Ф1830×7000

24.1

23

≤25

0.074-0.4

7.5-17

245

43.8

Ф2100×3000

23.7

15

≤25

0.074-0.4

6.5-36

155

34.8

Ф2100×4500

23.7

24

≤25

0.074-0.4

8-43

245

42

Ф2100×7000

23.7

26

≤25

0.074-0.4

8-48

280

56.6

Ф2200×4500

21.5

27

≤25

0.074-0.4

9-45

280

51.8

Ф2200×6500

21.7

35

≤25

0.074-0.4

14-26

380

60

Ф2200×7000

21.7

35

≤25

0.074-0.4

15-28

380

62

Ф2200×7500

21.7

35

≤25

0.074-0.4

15-30

380

64.8

Ф2400×3000

21

23

≤25

0.074-0.4

7-50

245

58

Ф2400×4500

21

30

≤25

0.074-0.4

8.5-60

320

69

Ф2700×4000

20.7

40

≤25

0.074-0.4

12-80

380

94

Ф2700×4500

20.7

48

≤25

0.074-0.4

12-90

480

102




Features of Mini Cement Grinding Plant Ball Mill For Sale

(1) The Ball Grinding Mill is an efficient tool for grinding many materials into fine powder;
(2) The Ball Grinding Mill is used to grind many kinds of mine and other materials, or to select the mine;
(3) The Ball Grinding Mill is widely used in building material, and chemical industry.
(4) There are two ways of grinding: the dry way and the wet way.
(5) The Ball Grinding Mill can be divided into tabular type and flowing type according to different expelling mine.
(6) To use the Ball Grinding Mill , the material to be ground is loaded into the neoprene barrel that contains grinding media.
(7) As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours.
(8) The longer the Ball Grinding Mill runs, the finer the powder will be.
(9) Ultimate particle size depends entirely on how hard the material you're grinding is, and the time how long the Ball Grinding Mill runs.

(10) Our Ball Grinding Mill have been used to grind glass, powder food products, create custom varnishes, make ceramic glaze, powder various chemicals.


Small Ball Mill
